2563#CASHFLOW ATM#Hyosung #2800SE #2800T #5200SE,5200 OPL LCD Cable (S3300000335) — Repair

The S3300000335: LCD Cable is a critical part for the OPL category in Hyosung 5200SE and 5200 ATMs. Designed for use in repair centers, this cable ensures reliable connectivity between the LCD and mainboard, supporting optimal display performance in compatible machine configurations.

Product Details

Part #: S3300000335

Part Name: 1.050: LCD CABEL: S3300000335: #2800SE #2800T #5200SE,5200 / OPL: Hyosung

Category: OPL

Machine: #2800SE #2800T #5200SE,5200

Repair Category: REPAIR (This part is replaced at a repair center, not in the field.)

Recommended Inventory: Category D (It is recommended to stock 2% of this part for every 100 Hyosung #2800SE #2800T #5200SE,5200 ATMs deployed. Note: The correct stocking levels are A=5%, B=4%, C=3%, D=2%, E=1%.)

Compatibility Summary

Machine: MX5200SE, MX5200

CDU: CDUL3, 2K, 4K, 6K, CDUL3_1K, CDUM, CDU21

MCR (Card Reader): EMV

Safe/Lock: BIZ, LEVEL1

Country/Region: US, CA, US_KR

Q&A

1. What is S3300000335 for?

S3300000335 is the part number for the LCD Cable used in the OPL category of Hyosung 5200SE and 5200 ATMs. It connects the LCD display to the mainboard, ensuring proper video signal transmission and display functionality.

2. Which machines are compatible with this LCD Cable?

This cable is compatible with Hyosung 5200SE and 5200 ATMs, specifically those with the compatible CDU, EMV card reader, and safe/lock types listed above.

3. What is the category of this part?

This part falls under the OPL (Operator Panel/Logic) category, which includes components related to the ATM's user interface and display systems.

4. Where is this part replaced?

This part is designated for replacement in a repair center (REPAIR category), not in the field.

5. What is the recommended quantity to keep in stock?

This part is classified as "D" in the Recommend QTY field, meaning it is recommended to keep 2% of this part in stock for every 100 compatible ATMs deployed. (A=5%, B=4%, C=3%, D=2%, E=1%)

6. What does OPL mean in the context of this part?

OPL stands for Operator Panel/Logic, referring to the ATM's interface and display systems. This cable is essential for connecting the LCD to the ATM's logic board.

7. Is this part compatible with all card reader types?

No, this part is specifically compatible with EMV card reader configurations as indicated in the Compatibility summary.
